Knox, Henry (1750-1806) Construction of a carriage for cannon which have their trunnions broken off [incomplete]
High-resolution images are available to schools and libraries via subscription to American History, 1493-1943. Check to see if your school or library already has a subscription. Or click here for more information. You may also order a pdf of the image from us here.
A high-resolution version of this object is available for registered users. LOG IN
Gilder Lehrman Collection #: GLC02437.00541 Author/Creator: Knox, Henry (1750-1806) Place Written: Boston, Massachusetts Type: Autograph manuscript Date: 1 March 1777 Pagination: 1 p. : docket ; 21.7 x 15.2 cm. Order a Copy
Drawing of a special carriage for a cannon, with the comment "A carriage for a Cannon if the trunnions be broken off. Many Cannon are mounted upon this construction at Boston." Trunnions are the knobs on both sides of a cannon that form the axis on which it pivots and hold it in place. Title from docket. The lower portion of the document may be missing.
